Plastic Pet Recycling Machine

Customization:	Available
Raw Material:	PET
Screw:	Double-Screw

Send Inquiry

Product Description

Basic Specifications

Model NO.:ATE

Inverter:Inverter

Automation:Automatic

Certification:CE, ISO9001:2008

Controller:Siemens PLC

Motor Brand:Siemens, Weg, Sew

Output Capacity:350-800kg/H

Suitable Material:PP/PE/PS/PA/Pet Plastic, Pet Flake

HS Code:8477209000

Plastic PET Recycling Machine Description

Plastic Pet Recycling Machine Processing

Twin screw extruder recycling & pelletizing system are applied to the waste materials which needs high processing performance of melting, volatilization, filtering etc., mainly works for the job of PET scraps recycling and re-pelletizing.

To slow down IV value reducing during PET scraps recycling, not only impurities, such as PVC content, moisture, etc., but also precise recycling system and reliable equipment configurations are necessary to put in the solution.

Special designed compactor: Applied to handle low bulk density scraps, such as film, filament, etc.
Pre-crystallization system: Required to pre-dry PET regrinds, flakes to guarantee final productions quality.

Technical Specifications

Model Name	ACT Series
Recycling Material	Waste film, filament, flakes, and regrinds of PET etc.
Final Product Shape	Pellets/ Granules
System Composition	Lifting-type drying hopper, Screw loader, Volumetric twin screw metering feeder, Twin screw extruder, Electric control system, water cooling strands pelletizing system.
Output Range	350kg/h-800kg/h
Screw Diameter	71.2/91mm (standard)
Vacuum Degassing	Double vented degassing (Standard)
Warranty	13 months since date of bill of lading

Key System Intelligence

🚀 Intelligence Start/Stop: One button only system to avoid manual operation errors. Interlocked modules follow logistical sequences automatically.

🛡️ Safety Protection: Each rotating part is equipped with electrical safe switches to ensure staff life safety.

🌐 Remote Monitoring: Ethernet and Bluetooth enabled for real-time information transmission and system monitoring.

Why Choose This System?

Combine crushing, compacting and pelletizing steps in one system, less-labor cost;
Higher efficiency feeding, suitable to film, filament, raffia, foaming materials;
Higher output and lower energy consumption;
Fast machine delivery: Average production of 10 sets per month.

Frequently Asked Questions

Q1: What materials can this recycling machine handle? A: It is ideal for PET waste including films, filaments, flakes, and regrinds. It also handles PP/PE/PS/PA materials.

Q2: How does the "One Button" system work? A: The intelligent control system uses a preset sequence to start or stop all modules automatically, preventing damage from improper manual operation.

Q3: How is the IV value maintained during PET recycling? A: Through precise temperature control, a pre-crystallization drying system, and optimized twin-screw plasticization to minimize degradation.

Q4: What is the typical delivery time for a system? A: The regular delivery time for a recycling machine is approximately 30 to 60 working days depending on the specific model.

Q5: Is overseas technical support available? A: Yes, overseas installation, staff training, and technical project design services are fully supported.
